The IES1G52UPDIN is an unmanaged industrial Gigabit switch with four 30 W PoE+ RJ-45 ports, an RJ-45/SFP combo port and a dedicated SFP slot. It is intended for fiber-connected PoE deployments in harsh environments from -40 °C to 75 °C.
Key features
- 4 x Gigabit PoE+ RJ-45 ports, up to 30 W each
- 120 W total PoE budget
- 1 dedicated SFP slot plus 1 RJ-45/SFP combo port
- Dual 48-56 V DC inputs via terminal block or DIN power connector
- IP30, DIN rail or wall mount
Specifications
| Access ports | 4 x 10/100/1000 RJ-45 PoE+ |
|---|---|
| Uplinks | 1 x SFP + 1 x RJ-45/SFP combo |
| PoE | IEEE 802.3af/at, up to 30 W per port |
| PoE budget | 120 W |
| Switching capacity | 12 Gbps |
| Layer | Layer 2 unmanaged |
| Management | Unmanaged |
| Form factor | DIN rail / wall, IP30 |
| Power supply | 48-56 V DC, dual redundant inputs |
| Operating temperature | -40 °C to 75 °C |
| Dimensions (W x H x D) | 4.13 x 1.43 x 5.59 in |
| Weight | 1.09 lb |
| Warranty | StarTech.com 2-year warranty |
Frequently asked questions
What is the PoE budget?
120 W, up to 30 W on each of the four PoE ports.
Are SFP modules included?
No, the SFP slots are open; included items are the switch, terminal block, mounting kit and guide.
What power input is required?
48-56 V DC via terminal block or DIN power connector, with dual redundant inputs.
Source: official StarTech.com datasheet.
StarTech.com 2-year warranty
- Access ports:
- 4 x 10/100/1000 RJ-45 PoE+
- Uplinks:
- 1 x SFP + 1 x RJ-45/SFP combo
- PoE:
- IEEE 802.3af/at, up to 30 W per port
- PoE budget:
- 120 W
- Switching capacity:
- 12 Gbps
- Layer:
- Layer 2 unmanaged
- Management:
- Unmanaged
- Form factor:
- DIN rail / wall, IP30
- Power supply:
- 48-56 V DC, dual redundant inputs
