The IESC1G50UP is an unmanaged 5-port Gigabit industrial switch with four PoE+ ports up to 30 W and a 120 W budget. It is intended for powering cameras and other PoE devices in harsh environments from -40 °C to 75 °C.
Key features
- 5 x 10/100/1000 RJ-45 ports, 4 with PoE+ (802.3af/at)
- Up to 30 W per PoE port, 120 W total budget
- Redundant 48-56 V DC power inputs
- IP30 housing, DIN rail or wall mount
- -40 °C to 75 °C operating temperature
Specifications
| Access ports | 5 x 10/100/1000 RJ-45 (4 PoE+) |
|---|---|
| PoE | IEEE 802.3af/at, up to 30 W per port |
| PoE budget | 120 W |
| Layer | Layer 2 unmanaged |
| Management | Unmanaged |
| Form factor | DIN rail / wall, IP30 |
| Power supply | 48-56 V DC redundant inputs (adapter not included) |
| Operating temperature | -40 °C to 75 °C |
| Dimensions (W x H x D) | 3.21 x 1.26 x 4.09 in |
| Weight | 0.33 lb |
| Warranty | StarTech.com 2-year warranty |
Frequently asked questions
What is the PoE budget?
120 W total, up to 30 W per PoE port.
Is a power adapter included?
No, power is supplied at 48-56 V DC via terminal block or barrel adapter (not included).
How many ports provide PoE?
Four of the five ports.
Source: official StarTech.com datasheet.
