Hubbell HBL7411GCB is a 20 A, 250 VAC three-phase non-NEMA Insulgrip male plug in black and white, for 3-pole 4-wire grounded industrial connections.
- Rating: 20 A, 250 VAC three-phase
- Poles and wires: 3 pole, 4 wire grounding
- Wire size: #16 AWG to #8 AWG, stranded copper only
- Cord range: 0.350 in to 1.150 in
- Terminals: #10-32 brass screw terminals
- Housing: nylon, brass blades
- Dimensions: 2.33 x 2.33 x 2.75 in
- Weight: 0.3 lb
- Listings: UL 498, CSA C22.2 No. 42
- Current:
- 20 A
- Voltage:
- 250 VAC, three-phase
- Poles and wires:
- 3 pole, 4 wire grounding
- Type:
- Extra heavy duty industrial, non-NEMA
- Wire size:
- #16 AWG to #8 AWG, stranded copper only
- Cord range:
- 0.350 in to 1.150 in
- Terminal type:
- Screw terminals, #10-32 brass
- Material:
- Nylon housing and cord clamp; brass blades; nickel-plated steel terminal clamp; clear polycarbonate terminal retainer
- Color:
- Black and white
- Dimensions:
- 2.33 in x 2.33 in x 2.75 in
- Weight:
- 0.3 lb
- Dielectric withstand:
- 2,000 V minimum
- Operating temperature:
- Max continuous 75 C, min -40 C without impact
- Certifications:
- UL 498, CSA C22.2 No. 42, Fed. Spec. W-C-596
- Model number:
- HBL7411GCB
