The NETGEAR MS108TUP is an 8-port 2.5G multi-gigabit smart managed switch with four 60 W Ultra60 PoE++ ports, four 30 W PoE+ ports and a 230 W budget. It is for small businesses that want Layer 2+ features and optional NETGEAR Insight cloud management.
Key features
- Eight 100M/1G/2.5G RJ-45 ports, all PoE
- Four 802.3bt ports up to 60 W and four 802.3at ports at 30 W, 230 W budget
- Layer 2+/Lite L3 smart management
- Web GUI, Lite CLI and optional NETGEAR Insight cloud management
- Fanless desktop design
Specifications
| Access ports | 8 x 100M/1G/2.5G RJ-45 PoE |
|---|---|
| PoE | Ports 1-4: 802.3bt up to 60 W; ports 5-8: 802.3at 30 W |
| PoE budget | 230 W |
| Switching capacity | 40 Gbps |
| Forwarding rate | 29.8 Mpps |
| Layer | L2+ / Lite L3 |
| Management | Web GUI, Lite CLI, NETGEAR Insight (optional) |
| Form factor | Desktop / wall mount |
| Power supply | External power adapter |
| Operating temperature | 32-104 °F (0-40 °C) |
| Dimensions (W x H x D) | 8.27 x 1.57 x 5.51 in |
| Weight | 1.98 lb |
| Warranty | NETGEAR limited lifetime hardware warranty |
Frequently asked questions
What is the PoE budget?
230 W total.
Can it be managed from the cloud?
Yes, NETGEAR Insight remote cloud management is available as an option, in addition to the local web GUI and Lite CLI.
Does it have a fan?
No, it is fanless (0 dBA).
Source: official NETGEAR datasheet.
