The NETGEAR MS324TXUP is a rackmount smart managed switch with 24 2.5G multi-gigabit Ultra60 PoE++ ports, four 10G SFP+ uplinks and a 720 W PoE budget. It is for small and mid-size businesses powering Wi-Fi 6/6E access points and other high-power PoE devices.
Key features
- 24 100M/1G/2.5G RJ-45 ports with 802.3bt PoE++ up to 60 W each
- Four dedicated 10G SFP+ uplinks
- 720 W PoE budget
- L2+/Lite L3 with IPv4/IPv6 static routing
- Web GUI, Lite CLI and optional NETGEAR Insight cloud management
Specifications
| Access ports | 24 x 100M/1G/2.5G RJ-45 PoE++ |
|---|---|
| Uplinks | 4 x 1G/10G SFP+ |
| PoE | 24 x 802.3bt PoE++ (60 W/port) |
| PoE budget | 720 W |
| Switching capacity | 200 Gbps |
| Forwarding rate | 148.8 Mpps |
| Layer | L2+ / Lite L3 |
| Management | Web GUI, Lite CLI, SNMP, NETGEAR Insight (optional) |
| Form factor | Rackmount (1U) |
| Power supply | Internal fixed PSU |
| Operating temperature | 32-122 °F (0-50 °C) |
| Dimensions (W x H x D) | 17.32 x 1.69 x 12.2 in |
| Weight | 9.79 lb |
| Warranty | NETGEAR limited lifetime hardware warranty |
Frequently asked questions
What is the PoE budget?
720 W, with up to 60 W per port on all 24 copper ports.
What uplinks does it have?
Four dedicated 10G SFP+ ports.
What is in the box?
Switch, power cord, rack-mount kit, rubber footpads, installation guide and a 1-year Insight subscription.
Source: official NETGEAR datasheet.
