The NETGEAR GS324TP (GS324TPv2) is a 24-port Gigabit PoE+ smart managed rackmount switch with 2 dedicated SFP ports. It is designed for small and mid-size business networks that need managed L2 features and PoE+ for endpoints.
Key features
- 24 x Gigabit PoE+ (802.3at) ports with a 190 W PoE budget
- 2 dedicated 1G SFP fiber ports
- 1U rackmount chassis with internal power supply
- IEEE 802.1Q VLANs with Auto-VoIP and Auto-Video VLAN
- L2/L3/L4 ingress ACLs and 802.1X RADIUS port authentication
Specifications
| Access ports | 24 x 10/100/1000 RJ-45 PoE+ |
|---|---|
| Uplinks | 2 x 1G SFP |
| PoE | 24 x 802.3at PoE+ |
| PoE budget | 190 W |
| Switching capacity | 52 Gbps |
| Forwarding rate | 38.6 Mpps |
| Layer | L2 (static routing not supported per datasheet) |
| Stacking | Not supported (not listed) |
| Management | Web GUI (HTTP/HTTPS), Smart Control Center, SNMP v1/v2c/v3, RMON |
| Form factor | 1U rackmount, 2 fans |
| Power supply | Internal, fixed |
| Operating temperature | 0-50 °C per datasheet layout |
| Dimensions (W x H x D) | 17.32 x 1.69 x 10.12 in |
| Weight | 7.78 lb |
| Warranty | NETGEAR 3-year limited hardware warranty |
Frequently asked questions
What is the PoE budget?
190 W across 24 PoE+ ports.
Is the power supply internal?
Yes, a fixed internal power supply.
Does it support static routing?
No, the datasheet lists IPv4 static routing as NA for GS324TPv2.
Source: official NETGEAR datasheet.
