The NETGEAR M4250-10G2F-PoE+ (GSM4212P) is a 1U managed switch with 8 Gigabit PoE+ ports, 2 additional Gigabit RJ-45 ports and 2 SFP ports. It is aimed at small AV-over-IP and Pro AV rack installations.
Key features
- Pre-configured AV profiles for audio (Dante, Q-SYS, AES67, AVB) and video (NVX, SVSI, NDI, Dante)
- NETGEAR IGMP Plus for automatic multicast across M4250/M4300/M4350/M4500 networks
- Lite Layer 3: IPv4/IPv6 static routing, RIPv2, PIM multicast routing, DHCP server and relay
- Dedicated AV web UI plus IT web GUI, CLI, SSH and SNMP; supported by NETGEAR Engage Controller
- Selectable fanless, quiet or cool fan modes
Specifications
| Access ports | 8 x 10/100/1000 RJ-45 PoE+ + 2 x 10/100/1000 RJ-45 |
|---|---|
| Uplinks | 2 x 1000BASE-X SFP |
| PoE | 8 x PoE+ (30 W/port) |
| PoE budget | 125 W |
| Switching capacity | 24 Gbps |
| Forwarding rate | 17.86 Mpps |
| Layer | L2 / Lite L3 (static routing, RIPv2, PIM) |
| Stacking | Not supported |
| Management | AV web UI, IT web GUI, CLI, SNMP; NETGEAR Engage Controller |
| Form factor | 1U rackmount (half-depth) |
| Power supply | Internal fixed PSU (C14 inlet) with on/off switch |
| License | AVB requires optional electronic license |
| Dimensions (W x H x D) | 17.32 x 1.7 x 7.87 in |
| Weight | 6.28 lb |
| Warranty | NETGEAR Enterprise Lifetime Warranty (Lifetime ProSAFE Hardware Warranty) |
Frequently asked questions
What is the PoE budget?
The PoE budget is 125 W.
Can M4250 switches be stacked?
No. NETGEAR lists stacking as not supported on the M4250 series; switches are interconnected with Auto-LAG/Auto-Trunk and IGMP Plus instead.
What power supply does it use?
Internal fixed PSU (C14 inlet) with on/off switch.
Source: official NETGEAR datasheet.
NETGEAR Enterprise Lifetime Warranty (Lifetime ProSAFE Hardware Warranty)
- Access ports:
- 8 x 10/100/1000 RJ-45 PoE+ + 2 x 10/100/1000 RJ-45
- Uplinks:
- 2 x 1000BASE-X SFP
- PoE:
- 8 x PoE+ (30 W/port)
- PoE budget:
- 125 W
- Switching capacity:
- 24 Gbps
- Layer:
- L2 / Lite L3 (static routing, RIPv2, PIM)
- Stacking:
- Not supported
- Management:
- AV web UI, IT web GUI, CLI, SNMP; NETGEAR Engage Controller
- Form factor:
- 1U rackmount (half-depth)
- Power supply:
- Internal fixed PSU (C14 inlet) with on/off switch
- License:
- AVB requires optional electronic license
