The FortiSwitch 1048G is a 1RU Layer 2/3 switch with 48x 10G/1G SFP+/SFP ports, 6x 100G/40G QSFP28/QSFP+ ports, MACsec and dual hot-swappable AC power supplies. It targets campus core and data center aggregation and is FortiGate switch controller compatible.
Key features
- 48x 10G/1G SFP+/SFP and 6x 100G/40G QSFP28/QSFP+ ports
- 2160 Gbps switching capacity, 2000 Mpps
- MACsec support
- Dual hot-swappable AC power supplies, front-to-back airflow
- 32 MB packet buffer, 128 GB SSD
Specifications
| Access ports | 48 x 10G/1G SFP+/SFP |
|---|---|
| Uplinks | 6 x 100G/40G QSFP28/QSFP+ |
| PoE | Not supported |
| Switching capacity | 2160 Gbps |
| Forwarding rate | 2000 Mpps |
| Layer | Layer 2/3 |
| Management | FortiLink (FortiGate switch controller) or standalone |
| Form factor | 1RU rack mount |
| Power supply | Dual hot-swappable AC, 100-240V; 585.78 W max |
| Operating temperature | 32 to 104 F (0 to 40 C) |
| Dimensions (W x H x D) | 17.27 x 1.69 x 18.11 in |
| Weight | 20.06 lb |
| Warranty | Fortinet Limited Lifetime Warranty |
Frequently asked questions
Are power supplies included?
Yes. The datasheet lists dual hot-swappable AC power supplies.
What ports does it have?
48x 10G/1G SFP+/SFP and 6x 100G/40G QSFP28/QSFP+ ports, plus a service port and RJ-45 console.
What is the switching capacity?
2160 Gbps (duplex; full line rate at 128-byte minimum packet size), 2000 Mpps.
Source: official Fortinet datasheet.
Fortinet Limited Lifetime Warranty
- Access ports:
- 48 x 10G/1G SFP+/SFP
- Uplinks:
- 6 x 100G/40G QSFP28/QSFP+
- PoE:
- Not supported
- Switching capacity:
- 2160 Gbps
- Layer:
- Layer 2/3
- Management:
- FortiLink (FortiGate switch controller) or standalone
- Form factor:
- 1RU rack mount
- Power supply:
- Dual hot-swappable AC, 100-240V; 585.78 W max
