Hubbell HBL8809C is a white twist-lock industrial flanged receptacle (NEMA L2-20R) rated 20 A, 250 V, with back and side wired screw terminals.
- Rating: 20 A, 250 V AC, single phase, 2 poles, 2 wires non-grounding
- Wire size: #16 to #10 AWG, solid or stranded copper
- Dimensions: 2.56 in x 2.56 in x 1.72 in; weight 0.10 lb
- Operating temperature: 75 C max continuous, -40 C min without impact
- Amperage:
- 20 A
- Voltage:
- 250 V AC
- Poles:
- 2
- Wires:
- 2 (non-grounding)
- Connector:
- NEMA L2-20R
- Wire size:
- #16 to #10 AWG solid or stranded copper
- Housing material:
- Nylon
- Contacts:
- Brass
- Color:
- White
- Dimensions:
- 2.56 in x 2.56 in x 1.72 in (L x W x H)
- Weight:
- 0.10 lb
- Dielectric strength:
- 2,000 V minimum
- Certifications:
- UL 498 terminal identification; Fed. Spec. W-C-596
