Hubbell HBL7764C is a black and white female Insulgrip twist-lock connector body rated 50 A, 250 VDC / 600 VAC, 3-pole 4-wire grounding, non-NEMA, for heavy-duty industrial cord connections.
- Rating: 50 A, 250 VDC / 600 VAC
- Cord range: 0.830 in to 1.250 in (21.08 mm to 31.75 mm)
- Terminals: pressure terminal screws, stainless steel
- Materials: nylon housing, brass contacts, polyester cord grip
- Dimensions: 2.56 in x 2.56 in x 6.50 in; weight 1.05 lb
- Certified to CSA C22.2 No.42; listed to UL 498
- Amperage Rating:
- 50 A
- Voltage Rating:
- 250 VDC / 600 VAC
- Number of Poles:
- 3
- Number of Wires:
- 4
- Cord Range:
- 0.830 in to 1.250 in (21.08 mm to 31.75 mm)
- Dimensions:
- 2.56 in x 2.56 in x 6.50 in
- Weight:
- 1.05 lb
- Material:
- Nylon
- Color:
- Black, White
- NEMA Rating:
- Non-NEMA
