Hubbell HBL26522 is a 60 A, 600 VAC non-NEMA flanged inlet with a steel housing, for 4-pole 5-wire grounded connections.
- Rating: 60 A, 600 VAC
- Poles and wires: 4 pole, 5 wire grounding
- Housing: zinc-plated steel flange, phenolic inlet interior
- Terminals: pressure terminal screws, #8 AWG to #4 AWG
- Dimensions: 3.95 x 4.12 x 4.12 in
- Weight: 1.75 lb
- Listings: CSA and UL
- Current:
- 60 A
- Voltage:
- 600 VAC
- Poles and wires:
- 4 pole, 5 wire grounding
- Material:
- Zinc-plated steel flanged housing; phenolic inlet; brass contacts; copper terminals; stainless steel terminal screws
- Color:
- Blue
- Terminal type:
- Pressure terminal screws, #8 AWG to #4 AWG
- Dimensions:
- 3.95 in x 4.12 in x 4.12 in (L x W x H)
- Weight:
- 1.75 lb
- Certifications:
- CSA and UL listed
