The FS S3270-24TM is a fanless 1U L2+ managed switch with 24 Gigabit RJ45 ports and 4 x 2.5G SFP uplinks. It is intended for small and medium business and branch access networks where silent operation is needed.
Key features
- 24 x 10/100/1000BASE-T RJ45 ports and 4 x 2.5G SFP uplinks
- 68 Gbps switching capacity and 50.59 Mpps forwarding rate
- Fanless design with internal 100-240 VAC power supply
- Managed via Web, CLI, SNMP and MACC cloud
- 1U rack-mount form factor
Specifications
| Access ports | 24 x 10/100/1000BASE-T RJ45 |
|---|---|
| Uplinks | 4 x 2.5G SFP |
| PoE | No |
| Switching capacity | 68 Gbps |
| Forwarding rate | 50.59 Mpps |
| Layer | L2+ |
| Management | Web, CLI (Telnet/console), SNMP, Syslog, NTP, TFTP, MACC cloud |
| Form factor | 1U rack-mount, fanless |
| Power supply | 1 internal AC, 100-240 VAC; 25 W max |
| Operating temperature | 0 to 45 °C (32 to 113 °F) |
| Dimensions (W x H x D) | 17.32 x 1.71 x 8.66 in |
| Weight | 5.51 lb |
| Warranty | FS 5-year limited warranty |
Frequently asked questions
Does the S3270-24TM have fans?
No. The datasheet lists it as fanless.
What uplinks does it have?
4 x 2.5G SFP uplink ports.
What is the maximum power consumption?
The datasheet lists a 25 W power rating (maximum consumption).
Source: official FS datasheet.
FS 5-year limited warranty
- Access ports:
- 24 x 10/100/1000BASE-T RJ45
- Uplinks:
- 4 x 2.5G SFP
- PoE:
- No
- Switching capacity:
- 68 Gbps
- Layer:
- L2+
- Management:
- Web, CLI (Telnet/console), SNMP, Syslog, NTP, TFTP, MACC cloud
- Form factor:
- 1U rack-mount, fanless
- Power supply:
- 1 internal AC, 100-240 VAC; 25 W max
