The FortiSwitch 124G-FPOE is a 1RU Layer 2 switch with 24x 2.5G RJ45 ports (8 with 802.3bt PoE and 16 with 802.3af/at PoE) and 6x 10G SFP+ ports, with a 780 W PoE budget. It suits branches deploying multi-gig Wi-Fi access points and PoE devices under FortiGate management.
Key features
- 24x 2.5G/1G/100M/10M RJ45 ports
- 8x PoE bt and 16x PoE af/at ports, 780 W PoE budget
- 6x 10G/1G SFP+/SFP ports
- 240 Gbps switching capacity, 355 Mpps
- Built-in AC power supply, 1RU rack mount
Specifications
| Access ports | 24 x 2.5G/1G/100M/10M RJ45 PoE |
|---|---|
| Uplinks | 6 x 10G/1G SFP+/SFP |
| PoE | 8 ports 802.3bt, 16 ports 802.3af/at |
| PoE budget | 780 W |
| Switching capacity | 240 Gbps |
| Forwarding rate | 355 Mpps |
| Layer | Layer 2 |
| Management | FortiLink (FortiGate switch controller) or standalone; on-premise and cloud-based management options |
| Form factor | 1RU rack mount |
| Power supply | Internal AC, 100-240V; 880 W max |
| Operating temperature | 23 to 113 F (-5 to 45 C) |
| Dimensions (W x H x D) | 17.3 x 1.71 x 12.2 in |
| Weight | 10.72 lb |
| Warranty | Fortinet Limited Lifetime Warranty |
Frequently asked questions
What is the PoE budget?
780 W, with 8 PoE bt ports and 16 PoE af/at ports.
What uplinks are included?
6x 10G/1G SFP+/SFP ports.
Is the power supply internal?
Yes, AC built in; no redundant power.
Source: official Fortinet datasheet.
