The AXIS D8004 is an unmanaged desktop switch with four 10/100 Mbps PoE ports and one 10/100 uplink port, with a 60 W total PoE budget. It is aimed at small surveillance installations that need to power a few cameras.
Key features
- 4 x 10/100 RJ-45 PoE ports and 1 x 10/100 RJ-45 uplink
- 60 W total PoE budget: 4 x 15 W, 2 x 30 W or 1 x 30 W + 2 x 15 W
- IEEE 802.3af/at support
- External power adapter included
- Brackets and rubber feet included
Specifications
| Access ports | 4 x 10/100 RJ-45 PoE |
|---|---|
| Uplinks | 1 x 10/100 RJ-45 |
| PoE | IEEE 802.3af/at, up to 30 W per port |
| PoE budget | 60 W |
| Layer | Layer 2 unmanaged |
| Management | Unmanaged |
| Form factor | Desktop / bracket mount |
| Power supply | External adapter, 100-240 V AC, max 62 W |
| Operating temperature | 0 °C to 50 °C (32 °F to 122 °F) |
| Dimensions (W x H x D) | 3.54 x 0.83 x 3.15 in |
| Weight | 0.38 lb |
| Warranty | Axis 3-year warranty |
Frequently asked questions
What is the PoE budget?
60 W total, configurable as 4 x 15 W, 2 x 30 W or 1 x 30 W + 2 x 15 W.
Is the power adapter included?
Yes, a power adapter and power cord are included.
Is it managed?
No, it is an unmanaged switch.
Axis 3-year warranty
