The Cisco C1300-24FP-4X is a Catalyst 1300 Series managed switch with 24 x 10/100/1000 RJ-45 PoE+ ports and 4 x 10G SFP+ uplinks, delivering a 375 W PoE+ budget. It is designed for small and medium-sized businesses and branch offices that need fully managed Layer 3 switching.
Key features
- 24 x 10/100/1000 RJ-45 PoE+ ports plus 4 x 10G SFP+ uplinks
- 128 Gbps switching capacity and 95.23 Mpps forwarding rate
- PoE+ on 24 ports with a 375 W power budget
- Layer 3 routing with static routes and RIPv2
- 1 fan design with internal power supply
Specifications
| Access ports | 24 x 10/100/1000 RJ-45 PoE+ |
|---|---|
| Uplinks | 4 x 10G SFP+ |
| PoE | PoE+ on 24 ports |
| PoE budget | 375 W |
| Switching capacity | 128 Gbps |
| Forwarding rate | 95.23 Mpps |
| Layer | Layer 3 (static routing, RIPv2, policy-based routing, DHCP server/relay) |
| Stacking | Up to 8 units via 10G ports (with other C1300 4X models) |
| Management | Web UI, CLI, SNMP v1/v2c/v3, Cisco Business Dashboard, Cisco Business mobile app |
| Form factor | 1RU rack-mountable, 1 fan |
| Power supply | Internal, 100-240 V AC |
| License | None required |
| Operating temperature | 23 to 122 F (-5 to 50 C) |
| Dimensions (W x H x D) | 17.49 x 1.73 x 13.78 in |
| Weight | 10.84 lb |
| Warranty | Limited lifetime warranty with return-to-factory replacement |
Frequently asked questions
Is the power supply internal or external?
The C1300-24FP-4X uses an internal 100-240 V AC power supply.
Does it support PoE?
Yes, PoE+ on 24 ports with a 375 W power budget.
Can it be stacked?
Yes, up to 8 units in a stack using 10G interfaces; only switches of the same stacking family can be stacked together.
Source: official Cisco datasheet.
Limited lifetime warranty with return-to-factory replacement
- Access ports:
- 24 x 10/100/1000 RJ-45 PoE+
- Uplinks:
- 4 x 10G SFP+
- PoE:
- PoE+ on 24 ports
- PoE budget:
- 375 W
- Switching capacity:
- 128 Gbps
- Layer:
- Layer 3 (static routing, RIPv2, policy-based routing, DHCP server/relay)
- Stacking:
- Up to 8 units via 10G ports (with other C1300 4X models)
- Management:
- Web UI, CLI, SNMP v1/v2c/v3, Cisco Business Dashboard, Cisco Business mobile app
- Form factor:
- 1RU rack-mountable, 1 fan
- Power supply:
- Internal, 100-240 V AC
- License:
- None required
