The Cisco C1300-8P-E-2G is a Catalyst 1300 Series managed switch with 8 x 10/100/1000 RJ-45 PoE+ ports and 2 x 1G copper/SFP combo uplinks, delivering a 67 W PoE+ budget. It is designed for small and medium-sized businesses and branch offices that need fully managed Layer 3 switching.
Key features
- 8 x 10/100/1000 RJ-45 PoE+ ports plus 2 x 1G copper/SFP combo uplinks
- 20 Gbps switching capacity and 14.88 Mpps forwarding rate
- PoE+ on 8 ports with a 67 W power budget
- Layer 3 routing with static routes and RIPv2
- Fanless design with external power supply
Specifications
| Access ports | 8 x 10/100/1000 RJ-45 PoE+ |
|---|---|
| Uplinks | 2 x 1G copper/SFP combo |
| PoE | PoE+ on 8 ports |
| PoE budget | 67 W |
| Switching capacity | 20 Gbps |
| Forwarding rate | 14.88 Mpps |
| Layer | Layer 3 (static routing, RIPv2, policy-based routing, DHCP server/relay) |
| Stacking | Not supported |
| Management | Web UI, CLI, SNMP v1/v2c/v3, Cisco Business Dashboard, Cisco Business mobile app |
| Form factor | 1RU rack-mountable, fanless |
| Power supply | External, 100-240 V AC |
| License | None required |
| Operating temperature | 23 to 122 F (-5 to 50 C) |
| Dimensions (W x H x D) | 10.55 x 1.73 x 7.28 in |
| Weight | 3.79 lb |
| Warranty | Limited lifetime warranty with return-to-factory replacement |
Frequently asked questions
Is the power supply internal or external?
The C1300-8P-E-2G uses an external 100-240 V AC power supply.
Does it support PoE?
Yes, PoE+ on 8 ports with a 67 W power budget.
Can it be stacked?
No, stacking is not listed for this model.
Source: official Cisco datasheet.
Limited lifetime warranty with return-to-factory replacement
- Access ports:
- 8 x 10/100/1000 RJ-45 PoE+
- Uplinks:
- 2 x 1G copper/SFP combo
- PoE:
- PoE+ on 8 ports
- PoE budget:
- 67 W
- Switching capacity:
- 20 Gbps
- Layer:
- Layer 3 (static routing, RIPv2, policy-based routing, DHCP server/relay)
- Stacking:
- Not supported
- Management:
- Web UI, CLI, SNMP v1/v2c/v3, Cisco Business Dashboard, Cisco Business mobile app
- Form factor:
- 1RU rack-mountable, fanless
- Power supply:
- External, 100-240 V AC
- License:
- None required
