The AXIS Camera Station S2216 Mk II Rack Appliance is a video recording appliance with an integrated 16-port PoE switch, 8 TB of storage and AXIS Camera Station Pro licenses for 16 channels. It is intended for small and mid-size surveillance sites that want recording, camera power and video management in one unit.
Key features
- Integrated 16-port Gigabit PoE switch, IEEE 802.3at Class 4
- 260 W total PoE budget
- 8 TB storage installed, 4 HDD bays
- 16 AXIS Camera Station Pro Core Device NVR licenses included
- Intel Core i3, 16 GB DDR5, Windows 11 IoT Enterprise LTSC 2024
Specifications
| Access ports | 16 x 1 Gbps RJ-45 PoE |
|---|---|
| Uplinks | 1 x SFP 1 Gbps + 1 x RJ-45 1 Gbps (switch side); 1 x RJ-45 1 Gbps (server) |
| PoE | IEEE 802.3at Class 4 |
| PoE budget | 260 W |
| Management | AXIS Camera Station Pro |
| Form factor | 1U rack |
| Power supply | Internal, 100-240 V AC, max 520 W |
| License | 16 AXIS Camera Station Pro Core Device NVR licenses |
| Operating temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Dimensions (W x H x D) | 18.74 x 1.77 x 17.32 in |
| Weight | 24.25 lb |
| Warranty | Axis 5-year warranty (recorder and hard drive) |
Frequently asked questions
What is the PoE budget?
260 W total across the 16 PoE ports.
How many cameras are supported?
It is qualified for up to 16 video channels, with a total recording rate up to 256 Mbps.
Are licenses included?
Yes, 16 AXIS Camera Station Pro Core Device NVR licenses are included.
Axis 5-year warranty (recorder and hard drive)
- Access ports:
- 16 x 1 Gbps RJ-45 PoE
- Uplinks:
- 1 x SFP 1 Gbps + 1 x RJ-45 1 Gbps (switch side); 1 x RJ-45 1 Gbps (server)
- PoE:
- IEEE 802.3at Class 4
- PoE budget:
- 260 W
- Management:
- AXIS Camera Station Pro
- Form factor:
- 1U rack
- Power supply:
- Internal, 100-240 V AC, max 520 W
- License:
- 16 AXIS Camera Station Pro Core Device NVR licenses
