Key Features
- Standard IEC 60320 C14 plug to C13 connector
- Orange jacket for easy identification of redundant power paths
- Rated for 13 Amps, 250 Volts AC
- 16 AWG conductor
- North America SJT cable jacket
- 0.9 Meter / 3 Feet cord length
Documentation
- Technical Drawing
- Certificate of Compliance
- Certificate of Origin
- REACH Compliance
- RoHS Compliance
- Prop 65 Declaration
- WEEE Compliance
- Product Lifecycle Statement
- ISO 9001:2015 QMS Certificate
Specifications
| Male Plug | IEC320 C14 |
| Female Connector | IEC320 C13 |
| Amperage | 13 Amps |
| Voltage | 250 Volts |
| Length | 0.9 Meter / 3 Feet |
| Tolerance | ± 35 mm / ± 1.4 inches for molded cords± 50 mm / ± 2 inches for mechanical cords |
| Conductor Gauge | 16 AWG |
| Conductor Count | 3 wires |
| Conductor Color Code | Black, White, Green | North American Color Code (NACC) |
| Outside Diameter | 7.6-8.0mm |
| Cable Jacket | North America SJT |
| Jacket Material | PVC |
| Jacket Temperature Rating | 105° C |
| Color | Orange |
| Testing | Each cord is tested for dielectric voltage-withstand (Hi-Pot), polarization and continuity. |
| Certification(s) | US & Canada - cULus |
| Packaging | Loose & Bundled |
Application Notes
IEC 60320 C14 to C13 Orange power cords are the most widely used jumper cords in IT infrastructure, providing standard power connections between rack-mounted PDUs and servers, network switches, storage arrays, KVM units, and other equipment with C13 inlets.
Color-coded cords simplify the identification of redundant power paths in data center and server rack environments. Using Orange cords for a dedicated power feed allows operations teams to verify dual-feed connections and trace circuits at a glance, reducing the risk of accidental disconnects during rack servicing.
Conductor gauge affects both the current-carrying capacity and the flexibility of the cord. A heavier gauge supports higher amperage loads and is appropriate for demanding applications, while a lighter gauge offers greater flexibility and is well-suited for lower-load devices and tight routing environments.
Product FAQs
Why use Orange power cords?
Color-coded power cords make it easy to identify redundant power paths at a glance. Using Orange cords for a specific power feed helps data center and operations teams quickly trace circuits, verify dual-feed connections, and reduce the risk of accidental disconnects during rack servicing.
How do I choose the right conductor gauge?
Conductor gauge determines the current-carrying capacity of the cord. A heavier gauge (lower AWG number) supports higher amperage loads, while a lighter gauge (higher AWG number) is more flexible and suited for lower-load devices. Always select a gauge that meets or exceeds the amperage requirements of your circuit and connected equipment.
What amperage rating should I select?
The cord's amperage rating is determined by its lowest-rated component — typically the connector or the wire gauge. Select the rating that matches the load requirements of your equipment, and ensure it does not exceed the capacity of your PDU outlet or circuit breaker.
What does the cable jacket affect?
The cable jacket affects flexibility, durability, and suitability for specific environments. SJT is more durable and rigid than SVT cordage.
