The NETGEAR M4350-48G4XF (GSM4352) is a Layer 3 managed switch with 48 Gigabit PoE+ ports and four 10G SFP+ uplinks. It is intended for AV-over-IP and enterprise access networks that need a PoE budget scalable with modular PSUs.
Key features
- 48 Gigabit PoE+ ports, PoE budget expandable to 1,440 W
- Four 10G SFP+ uplinks
- Two modular PSU slots for redundancy and EPS sharing
- Layer 3 with static, policy-based and dynamic routing
- Virtual Chassis stacking with non-stop forwarding
Specifications
| Access ports | 48 x 1G RJ-45 PoE+ |
|---|---|
| Uplinks | 4 x 10G SFP+ |
| PoE | 48 x PoE+ (30 W/port) |
| PoE budget | 236 W base, up to 1,440 W with modular PSUs |
| Layer | L3 (static, policy-based and dynamic routing) |
| Stacking | Virtual Chassis stacking with NSF and hitless failover |
| Management | AV web UI, CLI; NETGEAR Engage Controller |
| Form factor | 1U rackmount |
| Power supply | Internal 550 W PSU + 2 modular PSU slots (APS350Wv1/APS600Wv2/APS920Wv1/APS2000Wv1, sold separately) |
| Dimensions (W x H x D) | 17.32 x 1.7 x 15.75 in |
| Weight | 15.85 lb |
| Warranty | NETGEAR limited lifetime hardware warranty |
Frequently asked questions
What is the PoE budget?
236 W base from the internal PSU, expandable to 1,440 W (also 1,440 W redundant) with modular PSUs.
Are modular power supplies included?
No. It ships with an internal 550 W PSU; the two modular slots accept APS350Wv1, APS600Wv2, APS920Wv1 or APS2000Wv1, sold separately.
Can it be stacked?
Yes, using Virtual Chassis stacking with non-stop forwarding and hitless failover.
Source: official NETGEAR datasheet.
