The NETGEAR GS748T (GS748Tv6) is a 48-port Gigabit smart managed rackmount switch with 2 dedicated SFP and 2 combo copper/SFP ports. It targets businesses needing L2+ management and NETGEAR Insight cloud management without PoE.
Key features
- 48 x Gigabit RJ-45 ports plus 2 dedicated SFP and 2 combo SFP ports
- L2+/L3 Lite with static routing (32 IPv4 routes) and VLAN routing
- Web GUI plus NETGEAR Insight app/cloud management
- 256 VLANs and 16K MAC table
- Rackmount chassis with internal power supply
Specifications
| Access ports | 48 x 10/100/1000 RJ-45 |
|---|---|
| Uplinks | 2 x 1G SFP + 2 x 1G combo RJ-45/SFP |
| PoE | None |
| Switching capacity | 100 Gbps |
| Forwarding rate | 74.4 Mpps |
| Layer | L2+ / L3 Lite (IPv4 static routing) |
| Stacking | Not supported (not listed) |
| Management | Web GUI, SNMP v1/v2c/v3, NETGEAR Insight |
| Form factor | 1U rackmount, 2 fans |
| Power supply | Internal |
| Operating temperature | 0-45 °C (32-113 °F) |
| Dimensions (W x H x D) | 17.32 x 1.69 x 10.12 in |
| Weight | 7.63 lb |
| Warranty | NETGEAR Enterprise Limited Lifetime Warranty |
Frequently asked questions
How many fiber uplinks?
2 dedicated SFP ports and 2 combo copper/SFP ports.
Does it support PoE?
No.
Can it be managed from the cloud?
Yes, through NETGEAR Insight, as well as the local web GUI.
Source: official NETGEAR datasheet.
