The NETGEAR GS316P is a 16-port Gigabit unmanaged switch with PoE+ on all 16 ports in a fanless desktop/wall-mount metal case. It is a plug-and-play option for small offices powering IP cameras, phones and access points.
Key features
- 16 x Gigabit ports, all 802.3at PoE+ (up to 30 W per port)
- 115 W PoE budget, upgradable to 183 W with optional FlexPoE adapter
- Fanless, silent operation
- Plug-and-play unmanaged design
- Desktop or wall mount (wall mount kit included)
Specifications
| Access ports | 16 x 10/100/1000 RJ-45 PoE+ |
|---|---|
| Uplinks | None (no SFP) |
| PoE | 16 x 802.3at PoE+ |
| PoE budget | 115 W (up to 183 W with optional adapter) |
| Switching capacity | 32 Gbps |
| Forwarding rate | 1.488 Mpps per 1G port |
| Layer | Unmanaged L2 |
| Management | Unmanaged |
| Form factor | Desktop / wall mount, fanless |
| Power supply | External 130 W adapter, 54 V 2.4 A |
| Operating temperature | 0-45 °C (32-113 °F) |
| Dimensions (W x H x D) | 11.26 x 1.06 x 4.02 in |
| Weight | 1.94 lb |
| Warranty | NETGEAR 3-year limited hardware warranty (power adapter 2 years) |
Frequently asked questions
What is the PoE budget?
115 W, upgradable to 183 W with an optional FlexPoE power adapter.
Is it managed?
No, it is a plug-and-play unmanaged switch.
Does it have a fan?
No, it is fanless.
Source: official NETGEAR datasheet.
